Thermal Imaging Camera – Uncooled FPA Bolometer (160×120)
Technical Specifications:
Detector Type Uncooled FPA bolometer
Array size 160x120
Pixel size 25um
Spectral range 8-14um
Frame rate 12 Hz
Thermal sensitivity 0.10℃@30℃
Lens Focal...
More
Thermal Imaging Camera – Uncooled FPA Bolometer (160×120)
Technical Specifications:
Detector Type Uncooled FPA bolometer
Array size 160x120
Pixel size 25um
Spectral range 8-14um
Frame rate 12 Hz
Thermal sensitivity 0.10℃@30℃
Lens Focal length 3.8mm/F1.0
FOV 60°x45°
DOF range 0.1m~∞
Focus type Fixed lens
Interface type Fixed
Image IFOV 6.6mrad
Visible fusion High precision image fusion
Image Pseudo color 6 kinds （ iron, white hot, black hot, rainbow, cool metal, chrysophoron ）
display
Measure Measure range .-20℃~ +250℃
Measure accuracy ±2℃ or ±2%
Measure calibration Auto/manual ， shutter
Measure mode 6 movable spots, 6 movable areas with highest and lowest temp display and tracking, temp alarm (voice, color), Isothermal and difference measurement.
Temp color code Adjustable
Emissivity 0.01 ~ 1.0 adjustable （ increment 0.01 ）
Background temp calibration Yes
Atmospheric transmissivity Yes
Configuration Date/time/format, temperature un
Less
