SHOP DRAWINGS 17316B [718]

180" 12" 160" 42" 118" 25 FUNSTON RD - KANSAS CITY - KS 66115 PH: 913.281.7373 - RECEPTIONKC@RCSMILLWORK.COM 70.5" PROJECT: MEADOWBROOK MULTIFAMILY 4851 MEADOWBROOK PARKWAY PRAIRIE VILLAGE, KS 66207 DRAWING: 001 LEASING 001 5" CONTRACTOR: MW BUILDERS... More

180" 12" 160" 42" 118" 25 FUNSTON RD - KANSAS CITY - KS 66115 PH: 913.281.7373 - RECEPTIONKC@RCSMILLWORK.COM 70.5" PROJECT: MEADOWBROOK MULTIFAMILY 4851 MEADOWBROOK PARKWAY PRAIRIE VILLAGE, KS 66207 DRAWING: 001 LEASING 001 5" CONTRACTOR: MW BUILDERS ARCHITECT: 24" FJ PTM SOLID TRIM LOONEY RICKS KISS PAINT TO MATCH 6-14-2017 ISSUED FOR APPROVAL QZ-2 WALL REVISION 1 REVISION 2 REVISION 3 DATE APPROVED 39" DATE FIELD DIMENSIONED DATE RELEASED TO SHOP MATERIAL LEGEND 5 21" EXPOSED 1.05 MS-1: TABLEAUX GOLD LATTICE 1/8" ALUMINUM SHEET IN GOLD FINISH MS-2: ANTIQUE MIRROR 1/4" THICK 1 MS-3: INTEGRA FABRICS VOGUE MINX TUFTED FABRIC INSET PANEL MS-4: TABLEAUX 3/8" FAUX IRON ANTIQUE BRONZE FINISH 1.03 MS-6: TABLEAUX METAL SCREEN ANTIQUE BRONZE FINISH PG-1: 3FORM ONYX CROSS CUT HONEY HONED FINISH 3/8" X 48" X 96" PL-1: WILSONART VAPOR STRANDZ 4939K-18 LINEARITY FINISH WITH AEON PL-2: WILSONART CRISP LINEN 4942-38 FINE VELVET TEXTURE FINISH PL-3: WILSONART COLOMBIAN WALNUT 7943K-07 TEXTURED GLOSS Less
