SHOP DRAWINGS 17227 [140]

NOTE(S) 1. 1/8" RADIUS ON ALL EXPOSED EDGES 91.5" 92.5" M ILLWORK, L.C. 1554 NE 69TH PLACE, ANKENY, IA 50021 2.CT.3 2.CT.4 PH: 515.289.3787 - RCSMILLWORK@RCSMILLWORK.COM PROJECT: NEW HORIZON ACADEMY 12.75" 12.75" 450 SW 9TH STREET DES MOINES, IA FE SS-1... More

NOTE(S) 1. 1/8" RADIUS ON ALL EXPOSED EDGES 91.5" 92.5" M ILLWORK, L.C. 1554 NE 69TH PLACE, ANKENY, IA 50021 2.CT.3 2.CT.4 PH: 515.289.3787 - RCSMILLWORK@RCSMILLWORK.COM PROJECT: NEW HORIZON ACADEMY 12.75" 12.75" 450 SW 9TH STREET DES MOINES, IA FE SS-1 SS-1 FE DRAWING: LOCKER BANK CONTRACTOR: ESTES ARCHITECT: SIMONSON & ASSOCIATES ISSUED FOR APPROVAL REVISION # MATERIAL LEGEND: EXPOSED: SS-1 = LIVINGSTONE YUKON 3 PLAN @ LOCKER BANK 104 4 PLAN @ LOCKER BANK 207 2.01 SCALE : 1/2" = 1'-0" ArchRef A701 2.01 SCALE : 1/2" = 1'-0" ArchRef A701 1 2.05 92" 92" SEMI-EXPOSED: MEL-1 = WHITE MELAMINE 2.CT.1 2.CT.2 MEL-2 = BLACK MELAMINE EDGE BANDING: CABINET BODY: 3MM PVC TO MATCH DOOR/DRAWER FRONT: 3MM PVC TO MATCH 12.75" 12.75" SEMI-EXPOSED: WHITE PVC COUNTERTOP EDGE: BULLNOSE SS-1 SS-1 HARDWARE: PULLS: 4" WIRE TYPE (US26D) DRAWER SLIDES:TRU-TRAC TT100 FILE SLIDES: FULTERER 5755 LOWER HINGES: RPC 1.5" CONTINUOUS PIANO HINGES (CHROME) UPPER HINGES: RPC 376 FIVE KNUCKLE SUPPORTS: A&M (BLACK) JOB N Less
