English The 2WPGM is a two-way wireless PGM, which also provides one zone input. After assigning the PGM module to a system, the PGM can be programmed to activate and deactivate, as detailed in the system’s programming guide. The Backup Alarm Reporting option allows you to supervise the presence of the Magellan console. Location & Mounting The 2WPGM must be installed within 35 m (115 ft.) of the control panel. Before you mount the 2WPGM, perform the signal strength tests to ensure optimal performance of the unit. Do not cut, bend, or alter the antenna. Avoid mounting the PGM module near or on metal, as this may affect transmission. Powering the Unit The unit requires either AC or DC power input. For wire connections, see Figure 1. AC: 6 Vac (500 mA) to 16.5 Vac (200 mA) DC: 5 Vdc (500 mA) to 24 Vdc (200 mA) The external power supply used with this module must be of an Approved/ Certified type, acceptable to the authorities where the module is installed and used. Signal Strength Test To
