Caractéristique Volteis®
X2 VS2 Volteis®
X4 VS2
Driving license (* minimum age of 16 years) none* License A, B, (*A1, B1)
Vehicle dimensions (L x W x H), in mm 2750 x 1430 x 1520 2750 x 1430 x 1520
Weight (kerb) 681kg 740kg
Seating capacity 2 4
3-phase 28V 4-pole asynchronous ABM engine. Rated power 4Kw 8Kw
Battery pack (AGM sealed lead -ABT) 48V - 240Ah 48V 240Ah
Electronic controller yes yes
Vehicle diagnostics and configuration 48V 1400W 48V 1400W
Transmission type: automatic with 1/10 differential gear reduction rear wheel drive 2 driving wheels
Independent wheel suspensions with combined damper spring; Front:
double wishbone. Rear: swinging arm
Displacement : 80mm Displacement : 80mm
Disc brakes (front/rear) Ø 240/209mm Ø 240/209mm
Tyres 155 80 R13 155 80 R13
Performance Volteis®
X2 Volteis®
X4
Vs2 Vs2
Maximum speed 45km/h 70km/h
Average range (as per usage) 70km 60km
Consumption per 100km €1 €1
Charging time 6h 6h
Coefficient of climbing gradient 25% 60%
Availabl
