Line Reactors
What is a Line Reactor?
A Line Reactor absorbs many of the power line disturbances which otherwise damage or shut down your
inverters, variable speed controllers, or other sensitive equipment.
Line Reactors are the modern
technology solution to inverter and drive application problems.
Many of the AC reactors are harmonic compensated and IGBT
protected to assure optimum performance in the presence of
harmonics.
These reactors are very effective at reducing
harmonics produced by inverters and drives, and in most cases,
will help you meet IEEE 519.
Use harmonic compensated reactors
on either the input or output of an adjustable speed
drive/inverter.
There are two types of impedance ratings to choose from in Line
Reactors - three percent or five percent.
3% impedance reactors are usually sufficient to absorb power line spikes and motor current surges.
They will prevent nuisance tripping of drives or circuit breakers in most applications.
A 3% impedance
line reactor is
