XS 55 Resistive safety edge XS 55 SAFETY EDGE PRE-ASSEMBLED 2.5 METRE LONG KIT Content 1 rubber profile, 2.5 metre long 1 coupling terminal with 8.2 kOhm resistor XSP R8.2. 1 wired coupling terminal with wire. 1 aluminium profile, 2.5 metre long The new XS 55 safety edge is a FAAC SafeZone component for promoting automated system safety. The edge is a safety device certified in Category 2 according to EN 12978 for use in systems compliant to legal requirements. FAAC XS 55 is the only ‘Plug and Play’ rubber safety edge. • Rubber profile, 55 mm high. • Aluminium support profile. • Obstacle detection at +/- 60° angles. • Protection level IP65. • 8.2 kOhm resistance. NEW SAFETY EDGE TECHNICAL SPECIFICATIONS MATERIAL NEEDED FOR INSTALLING THE XS 55 SAFETY EDGE Product Description XS 55 Conductive rubber profile, 55 mm high. 25 metre coil. XSP R8.2 Coupling terminal with 8.2 kOhm resistor. Single box for each edge. XSP C0.5 Wired coupling terminal with 0.5 metre wire. Single box for each edg
