Technical characteristics DIMENSIONS AND TECHNICAL SPECIFICATIONS Model 746 C Z16 746 C Z20 Power supply 220 – 240 V ~ @50/60 Hz Max power 150 W All rights reserved. No part of this publication may be reproduced in whole or in part in any form or manner without the prior authorisation of FAAC S.p.A. Pinion Z16 Module 4 Z20 Module 4 Max. thrust force 830 N 665 N Max leaf weight 600 kg 400 kg Max. leaf speed 9.6 m/min 12 m/min In order to continuously improve the product, FAAC S.p.A. reserves the right to make technical modifications without prior notice. Max leaf width 40 m 50 m Stopping space 30 mm Intended use Industrial/Commercial/Residential Use frequency High traffic Protection rating IP44 Operating temperature -20°C to +65°C Start-up capacitor 12.5 μF Thermal protection 120°C automatic reset Weight 16.2 kg 16.5 kg Oil FAAC HP OIL 746 C and 844 C DIMENSIONS AND TECHNICAL SPECIFICATIONS Model 844 C Z16 Power supply 220 – 240 V ~ @50/60 Hz Max power 230 W Pinion Z16 Module 4 Max. thr
