GORDON-CHILDS HOUSE 127 Dyers Pass Road, 8022 Christchurch DRAWING LIST A-51(A) Lift & Slide Door details - Shiplap Weatherboard - Head & Sill 1:2 A-52(A) Lift & Slide Door details - Shiplap Weatherboard 1:2 A-01 Pre demo site survey - 12699 SS-01 Rev_A...
More
GORDON-CHILDS HOUSE 127 Dyers Pass Road, 8022 Christchurch DRAWING LIST A-51(A) Lift & Slide Door details - Shiplap Weatherboard - Head & Sill 1:2 A-52(A) Lift & Slide Door details - Shiplap Weatherboard 1:2 A-01 Pre demo site survey - 12699 SS-01 Rev_A 1:200 - Jamb & External corner A-02(C) Site Plan 1:200 A-53(B) Tilt & turn Window details - Stotherm Plaster - Head & Sill 1:2 A-03(C) Ground floor plan 1:100 A-54(B) Tilt & turn Window details - Stotherm Plaster - Sill & Jamb 1:2 A-04(E) Elevations north and south 1:100 A-55(B) Tilt & turn window to Stotherm plaster - internal corner 1:2 A-05(B) Elevations east and west 1:100 A-56(B) Hinged Inwards Door details - Stotherm Plaster - Head & Sill 1:2 A-06(B) Section A 1:50 A-57(B) Hinged Inwards Door details - Stotherm Plaster - Jamb 1:2 A-07(C) Section B 1:50 A-58(A) Opening Skylight details - Head, Sill & Jamb 1:5 A-08(A) Section C 1:50 A-09(B) Section D 1:50 A-59(A) Proposed ground floor electrical plan 1:100 A-10(A) Section E 1:50 A-6
